The Red Dot 71R4511 binary switch boot harness assembly is designed to provide a secure, durable electrical connection for binary pressure switch applications in mobile HVAC systems. It features a molded 2-wire boot that helps eliminate terminal corrosion and wire breakage, improving long-term reliability in harsh operating environments.
This harness includes 28-inch lead wires, offering installation flexibility while maintaining a protected connection. It is commonly used with Red Dot binary switch models 71R7000 and 71R7050 in heavy-duty and off-highway HVAC applications.
Use the specifications and interchange numbers below to confirm compatibility before ordering.
Product Specifications
-
Part Type: Binary Switch Boot Harness Assembly
-
Red Dot Part No.: 71R4511
-
Red Dot Factory Part No.: RD-5-12151-2P
-
Connector Type: Molded binary boot
-
Wiring: 2-wire connection
-
Lead Wire Length: 28″
-
Application: Binary switch models 71R7000, 71R7050
-
Function: Provides sealed electrical connection to binary pressure switches
-
Benefit: Reduces corrosion and terminal fatigue
Cross Reference Numbers
-
Texas Truck AC: 850-9527
-
AirSource (MEI): 1524
-
Alliance: ABP N83 318189, ABP N83 318259
-
NDNS: ABPN83318259
-
Omega: 33-R4510
-
Primatech: PTAC1524
-
Truck Air (MEI): 13455
-
TruckAC+: T2368
-
Red Dot (Aftermarket): 71R4511
-
Red Dot (Factory): RD-5-12151-2P
Interchange Numbers
1524, 232-8447, 41-6845, 4379-RD5121512, 4379-RD5121512P, 71R4511, 850-9527, 946-1000, ABP N83 318189, ABP N83 318259, RDHRD5121512P, RDT71R4511, SWI7000
