A trinary pressure switch helps protect the system while also supporting stable A/C operation under changing conditions. The Red Dot 71R7550 is a Generation II trinary pressure switch designed to provide low-pressure protection, high-pressure shutdown, and fan or shutter override in mobile HVAC systems.
This switch threads directly onto a male Schrader-type valve using a 7/16-20 UNF-2B female thread, allowing for straightforward installation without refrigerant recovery. It is rated for up to 28V DC, with electrical ratings that support common mobile HVAC loads, making it a reliable choice for heavy-duty, on-highway, and vocational equipment applications.
Use the specifications and interchange numbers below to confirm the correct match before ordering.
Product Specifications
-
Part Type: Trinary Pressure Switch (Generation II)
-
Aftermarket Part No.: 71R7550
-
Factory Part No.: RD-5-4583-0P
-
Thread Size: 7/16-20 UNF-2B Female
-
Install Style: Threads onto male Schrader-type valve
-
Max Voltage: 28V DC
-
Electrical Rating:
-
7 AMP resistive
-
4 AMP inductive
-
-
Application: Mobile A/C systems requiring compressor protection and fan/shutter control
OEM & Interchange Numbers
OEM Numbers:
-
Freightliner: A06-18015-000, RD-5-4583-0P
-
Mack: 1MR3506P2, 4379-RD545830, 4379-RD559770
-
Navistar: 1676658-C1
-
PACCAR: 865700, 865700BSM, 86570P, K301-239, K301-313-1
-
Western Star: 61522-3412
Aftermarket / Interchange:
-
Texas Truck AC: 850-8952
-
AirSource / MEI: 1560
-
Alliance: ABP N83 318029, ABP N83 318149
-
Bergstrom: 650633
-
Climatech: BC1000, BC10000
-
CoolCab: 901221
-
CoolStar / MEI: 923-1008
-
Euclid: E-807252
-
Fleetrite: ZGG19280
-
Four Seasons: 35901
-
Kysor: 2299003 (404172 old)
-
Motivaire: 44573
-
Murray: 207094
-
Primatech: PTAC1560
-
Red Dot Aftermarket: 71R7550 (alt: 71R7715)
-
Red Dot Factory: RD-5-5012-3
-
Road Choice: SWI3308
-
Roadforce: RF4756506662
-
Truck Air / MEI: 44889
-
TruckAC+: T6743
-
TTA/C: 14-5327
