The Red Dot R-9750-9P Off-Road Headliner Air Conditioner with Heat is engineered for off-highway equipment cabs that demand dependable climate control in compact overhead installations. Designed to mount in the headliner, this unit filters recirculating cab air and distributes airflow efficiently through four multi-directional louvers, putting comfort exactly where the operator needs it.
The system delivers 17,000 BTU/hr of cooling using R-134a refrigerant and a heater option rated at 25,600 BTU/hr, providing dependable performance across changing seasons. Strong airflow (240 CFM) ensures consistent temperature control, while the rugged construction supports long service life in high-vibration environments.
Operating on 12V DC, the R-9750-9P is well suited for construction, agricultural, and specialty equipment. 24V and A/C-only variants are also available to match system requirements.
Product Specifications
-
Manufacturer: Red Dot
-
Model Series: R-9750
-
Model Number: R-9750-9P
-
System Type: Headliner A/C Unit with Heat
-
Voltage: 12 VDC
-
Refrigerant Type: R-134a
Cooling Performance
-
Cooling Capacity: 17,000 BTU/hr
-
@ 36°F refrigerant temperature
-
80°F (26.7°C) wet bulb entering air
-
5.0 kW @ 2.2°C
-
Heating Performance
-
Heating Capacity: 25,600 BTU/hr
-
@ 100°F air temperature rise
-
7.5 kW @ 37.8°C
-
Air & Electrical
-
Air Flow: 240 CFM (408 m³/h)
-
Current Draw: 13 amps @ 13.6 VDC
-
Includes 4 amps for A/C clutch
-
Physical
-
Weight: 44 lbs (20 kg)
-
Dimensions: See product image #2
Installation Note:
Additional components may be required to complete an A/C system installation.
Cross Reference Numbers
-
Texas Truck A/C: 950-1160-3-12
-
AirSource – MEI: 13058
-
CoolStar – MEI: 990-9735
-
Primatech: PTAC10-9735
-
Red Dot Aftermarket: R-9750-9
-
Truck Air – MEI: 50-9735
-
TruckAC+: T3879
-
TTA/C: 90-9750-9
Interchange Numbers
-
10-9735
-
232-7886
-
4379-R97509P
-
R-9750-9P
-
R-9753-1P
-
RDH R9750 9
