The Red Dot R-4500-8-24P Rooftop Power Condenser is engineered for applications that require maximum condenser capacity and airflow. This dual-fan rooftop unit supports high-output evaporators and dual-evaporator systems, making it ideal for specialty vehicles and mission-critical installations where consistent performance is essential.
Featuring two 16-inch diameter fans producing a combined 2,011 CFM, the R-4500-8-24P delivers dependable heat rejection at elevated operating temperatures. Built for 24V DC electrical systems, it’s optimized for platforms that demand efficiency, durability, and continuous duty capability. A low-profile conversion kit is available for applications requiring reduced overall height (sold separately).
Product Specifications
-
Manufacturer: Red Dot
-
Model Series: R-4500
-
Model Number: R-4500-8-24P
-
System Type: Rooftop Power Condenser
-
Voltage: 24 VDC
Performance
-
Capacity: 45,200 BTU/hr
-
@ 135°F (57.2°C) condensing temperature
-
110°F (43.3°C) entering air
-
13.2 kW
-
Air & Electrical
-
Air Flow: 2,011 CFM (3,517 m³/h)
-
Fans: Two 16-inch diameter motors
Physical
-
Weight: ~79–85 lbs (listed)
Options
-
Low-profile conversion kit (sold separately)
Cross Reference Numbers
-
Texas Truck A/C: 950-3300-24
-
AirSource – MEI: 36434
-
Primatech: PTAC10-9399
-
Red Dot Aftermarket: R-4500-8-24
-
Truck Air – MEI: 50-9399
-
TruckAC+: T5511
-
TTA/C: 90-4500-8-24
Interchange Numbers
-
10-9399
-
232-7847
-
4379-R4500824
-
R-4500-8-24P
-
RDH R4500 8 24
