The Red Dot 71R8423 Bulbless Block-Type Expansion Valve is a plate-mount TXV engineered for heavy-duty mobile HVAC systems that require precise refrigerant control without an external sensing bulb. Bulbless block valves regulate internally, reducing components and improving durability in high-vibration off-highway equipment.
This model features a 5.5°F superheat rating for tight evaporator control and is designed for John Deere construction equipment equipped with Red Dot A/C units R-9450-3 and R-9475 series. With a 2-ton capacity, defined pressure limit, and plate/flange mounting, the 71R8423 delivers consistent performance in demanding worksite conditions.
Use the specifications and interchange numbers below to confirm the correct match before ordering.
Product Applications
-
John Deere Backhoe Loader / Tractor:
-
310E, 410E, 410G, 510E, 710E
-
With Red Dot A/C unit R-9450-3
-
-
John Deere Crawler Dozer:
-
450H, 550H, 650H, 700H
-
With Red Dot A/C units R-9475-0 and R-9475-0-24
-
-
Red Dot Units:
-
R-9475-0
-
R-9475-0-24
-
R-9475-3
-
Product Specifications
-
Part Type: A/C Expansion Valve
-
Valve Style: Bulbless Block-Type
-
Mounting Style: Plate / Flange Mount
-
Rated Capacity: 2 Ton
-
Red Dot Part No.: 71R8423
-
Red Dot Factory No.: RD-5-8100-0P
-
Superheat Rating: 5.5°F
-
Pressure Limit: 53.3 psig @ 90°F
Connections (Plate / Flange Mount):
Hose Side
-
Inlet: #6 (3/8 in.) Plate (Flange) Mount
-
Outlet: #12 (3/4 in.) Plate (Flange) Mount
Evaporator Side
-
Inlet: #8 (1/2 in.) Plate (Flange) Mount
-
Outlet: #10 (5/8 in.) Plate (Flange) Mount
OEM & Interchange Numbers
OEM Numbers:
-
John Deere: RD-5-8100-0P
-
Volvo: RDHRD581000P
Aftermarket / Interchange:
-
Alliance: ABP N83 308371
-
Red Dot Aftermarket: 71R8423
Additional Interchange References:
247-3712, 4379-RD581000P, EV01235, RDT71R8423
(Always verify plate-mount configuration, superheat rating, tonnage, and pressure limits prior to installation.)
