Compressor BT5-4759

Description

Interchange Numbers:
1401390, 1410022, 20-04042, 20-04042-S, 20-04042-S, 330-2456, 4042, 4379-RD5123340P, 4379-RD5123340P, 4432, 4432SAN, 4759, 5365, 75R81662, ABP N83 304741, ABP N83 304741, ACC3456, F69-1003, F69-6002-111, LE01110, RDHRD5123340P, RDT75R81662, RDT75R81662

ESSENTIAL SPECIFICATIONS
Compressor Family:
Style:
Mount Type: SD7
Ear ID:
Refrigerant: R134A
Displacement: 155.00
Rotation Direction: CW
Oil Qty (cc): 300
Cylinder Head: GQ
Port Angle: V
Port Clocking:
Head Port Style: O-Ring Compression
Rotor Size: 119
Rotor Groove: PV8
Gauge Line
to First Groove: 36.60
Gauge Line
to Middle Groove:
Gauge Line
to End Groove: 61.50
Coil Voltage: 12
Connector: 2 Wire Female Packard #15300002
