Coyote 4″ La Mesa Louver with 2½″ Hose Adapter (06-2002)

Description

Overview

The Coyote 06-2002 La Mesa Louver offers durable performance and flexible airflow control in a clean, round design.
Because it connects directly to a 2½″ flexible hose, it fits most standard HVAC ducts and installations.
The contoured grille provides even air distribution while reducing turbulence and system noise.
In addition, the sleek face and satin finish give it a professional look that complements modern equipment interiors.

---

Function and Performance

This La Mesa Series louver channels airflow smoothly through curved vanes for quiet and efficient operation.
The 2½″ rear hose adapter maintains consistent pressure and minimizes air loss in both heating and cooling systems.
As a result, it provides balanced airflow across cabin spaces or operator compartments.
In addition, the adjustable vent face allows users to direct air exactly where it’s needed.

---

Durability and Design

Coyote molds the 06-2002 from high-strength black ABS plastic that resists vibration, UV exposure, and temperature changes.
Because the adapter and face are molded as one piece, it provides a strong, leak-free connection.
The satin finish offers a clean, OEM-grade appearance and stands up to years of use.
In addition, the smooth internal airflow path minimizes static pressure, improving overall HVAC efficiency.

---

Installation

Installation is simple and secure.
Insert the La Mesa Louver into the panel opening, then connect the 2½″ flexible hose to the rear adapter.
Tighten the hose with a clamp or tie for a tight, leak-free seal.
Because the assembly is a one-piece design, it installs quickly with no need for extra fittings or fasteners.

---

Applications

The Coyote 06-2002 La Mesa Louver is used in buses, RVs, off-road machinery, trucks, and industrial HVAC systems.
It’s ideal for dash panels, ceiling vents, and bulkhead outlets where airflow direction and durability are important.
Because of its universal fit and clean design, it’s also popular for OEM installations and retrofit projects.

---

Specifications

• Series: La Mesa Louvers

• Part Number: 06-2002

• Face Diameter: 4″ (101.6 mm)

• Hose Adapter Size: 2½″ (63.5 mm)

• Material: Black ABS plastic

• Mounting Style: Panel-mount with integrated hose adapter

• Applications: Bus, RV, truck, off-road, and industrial HVAC

• Features: Adjustable airflow, quiet operation, durable one-piece design, easy installation
