BT3-0145 Fan – 9 Inch Puller, 12V

Description

The BTRAC BT3-0145 axial fan is engineered for mobile HVAC and equipment cooling systems operating on 12-volt electrical platforms. It is based on the SPAL VA07-AP12/C-58A platform and uses a 9-inch (225 mm) axial puller design to move air efficiently across condensers, radiators, and auxiliary heat exchangers.

Because the fan uses a fully sealed motor rated to IP68, it performs reliably in environments exposed to moisture, dust, vibration, and road spray. As a result, it works well in on-highway trucks, off-highway equipment, and vocational vehicles. In addition, the waterproof AMP electrical connector helps protect the wiring connection and supports long-term reliability.

The BT3-0145 is configured for suction (puller) operation, which makes it well suited for condenser and radiator applications where airflow must be drawn through the core. The compact, low-noise design also helps reduce operational sound while maintaining dependable airflow.

Furthermore, SPAL testing shows stable airflow across increasing static pressure, which supports consistent cooling under real-world operating conditions. Because of this, the BT3-0145 is a dependable OEM-style replacement fan for mobile cooling systems.

---

Specifications

Electrical

• Voltage: 12V DC

• Test Voltage: 13V DC

Fan & Configuration

• Fan Type: Axial

• Diameter: 9 in (225 mm)

• Airflow Direction: Puller (suction)

Construction

• Motor Type: Sealed, waterproof

• Ingress Protection: IP68

• Connector: AMP connector (Code 180908)

• Terminal Type: AMP terminal (Code 42098-2)

Physical

• Approximate Weight: 1.0 kg (2.2 lb)

• Mounting Hardware: M5

• Recommended Mounting Torque:

  • 3 Nm (+1 / −0)

---

Cross Reference Numbers

30100452
VA07-AP12/C-58A

---

Important Notes

• Designed for 12-volt mobile HVAC and cooling systems

• IP68 waterproof motor supports harsh operating environments

• Puller configuration for condenser and radiator applications

• Compact 9-inch axial fan for space-limited installations

• Always verify mounting depth, airflow direction, and electrical compatibility before installation
