77R1305 A/C Condenser – Multiflow

Description

The BTRAC 77R1305 A/C Condenser supports reliable cooling performance in demanding mobile environments. Its multiflow construction routes refrigerant through multiple flat tubes at the same time. As a result, the condenser improves heat transfer while maintaining stable system operation.

Because multiflow condensers provide high efficiency in a slim profile, the 77R1305 fits well in space-limited installations. In addition, the wide fin area promotes strong airflow across the core. Therefore, the system can respond quickly to changing loads while maintaining consistent cooling.

This condenser is commonly referenced with R-4480 Caterpillar condenser applications. These references identify a condenser family or configuration only and do not indicate refrigerant type. Always confirm compatibility by application, mounting, and connection requirements before installation.

When installed with proper airflow and secure mounting, the 77R1305 offers dependable service life for mobile and heavy-duty HVAC systems.

---

Construction & Design

• Multiflow (parallel-flow) condenser design

• Aluminum construction for durability and efficient heat transfer

• Compact, wide-core layout for improved airflow

• Built for mobile and heavy-duty HVAC environments

---

Dimensions

• Overall Width: 24 13/32 in

• Fin Width: 21 29/64 in

• Overall Height: 10 23/32 in

• Core Thickness: 1 in

---

Application / Series Reference

• Commonly associated with R-4480 Caterpillar condenser applications

• Suitable for mobile, off-highway, and heavy-duty HVAC systems

Series references identify condenser families only and do not specify refrigerant type.

---

Key Features

• Multiflow condenser construction

• Efficient heat rejection in a compact footprint

• Supports stable system pressures

• Durable design for heavy-duty use

• Ideal for OEM-style replacement and service applications

---

Interchange Numbers

2045-890, 350-2220, 4379-RD5120510P, 77R1305, ABP N83 306375, RDT77R1305
