Coyote Phoenix Series Snap-In Louver (06-2021-1)

Description

Overview

The Coyote 06-2021-1 Phoenix Louver combines high airflow performance with fast, tool-free installation.
Because it uses snap-fit tabs instead of screws, it installs cleanly and stays secure even in vibration-heavy environments.
This makes it perfect for applications where appearance, speed, and service access are priorities.

---

Function and Performance

This snap-in louver directs air through a rounded face for even, low-noise distribution.
Its internal vanes allow easy adjustment of both direction and volume.
As a result, operators can fine-tune airflow for better comfort and cab balance.
In addition, the snap-in design provides a tight fit, eliminating rattles or leaks common with looser fittings.

---

Durability and Design

Coyote molds the 06-2021-1 from impact-resistant black ABS plastic that resists vibration, heat, and UV exposure.
Because the face and mounting clips are integrated into one piece, it holds its shape and grip even under constant movement.
The satin finish blends well with other Coyote louvers and adds a clean, OEM-style appearance.

---

Installation

Installation is fast and tool-free.
Align the Phoenix louver with the panel opening and press firmly until the spring tabs snap into place.
Because the clips are flexible yet strong, they hold the vent tightly without hardware.
Removal for cleaning or replacement takes only seconds using a trim tool.

---

Applications

The Coyote 06-2021-1 Phoenix Series Snap-In Louver is used in buses, RVs, trucks, construction equipment, and industrial HVAC systems.
It’s ideal for dash panels, ceiling vents, and side outlets where clean styling and quick installation are important.
Because it requires no fasteners, it’s a favorite for OEM applications and field retrofits alike.

---

Specifications

• Series: Phoenix Louvers

• Part Number: 06-2021-1

• Face Type: Rounded with directional vanes

• Mounting Style: Snap-in (spring tab)

• Rear Connection: Optional hose adapter (sold separately)

• Material: Black ABS plastic

• Applications: Bus, RV, truck, off-road, industrial HVAC

• Features: Snap-in design, quiet airflow, adjustable vanes, durable construction
